Signal IO List for Single Fieldbus Architecture

Select Section ...

1. General Description

2. Column Description

3. Column Requirements

4. Example Signal IO List for Single Fieldbus Architecture

5. Downloads

1.

General Description

IO Listsare created and uploaded by the user, and they have an essential role in the PLC creation. Based on the information they provide, PLCCreator creates the PLC hardware configuration together with signal to IO module assignment, and corresponding PLC tags with their addresses and/or tag aliases.

The signal IO list for Single Fieldbus Architecture has 5 columns where user provides signal information:

On the Figure 1 below is shown an example signal IO list for Single Fieldbus Architecture:

Figure 1: Example of Signal IO list for Single Fieldbus Architecture

The columns in each row are linguistically interpreted as follows:

The signal identified with "Name", whose signal type is determined by "Signal Type", shall be wired in the PLC rack of the "Hardware Platform". This rack exclusively contains signals labeled with the specified "Group".

Based on the information they provide the above columns can be categorized into 2 groups:

Rack Creation Columns- these include"Hardware Platform"and"Group".

The information from these columns determines how many racks will be created and from which hardware platform.

For every distinct (unique) combination of the "Hardware Platform" and "Group" columns in the signal IO list, PLCCreator will create a separate rack with the specified hardware platform and associate the signals that have this specific combination of the "Hardware Platform" and "Group" columns.
IO Module Creation Columns- these include"Name", "Description"and"Signal Type".

These columns are inherited from Signal IO List for Single Rack Architecture and the information they provide is processed in the similar way, providing similar outputs:
1. Creation of IO modules within each rack created by "Rack Creation Columns". The IO modules are determined by the signal type specified with "Signal Type" column.
2. Generation of PLC tags based on the details provided in the "Name" and "Description" columns and assign them to the respective IO modules with proper tag address and/or tag name.

More information for thecolumn descriptionandcolumn requirementscan be found in the further text.

The IO List Templates and examples can be downloaded either from theDownloadssection below or from theIO List Templatesdownload page.

2.

Column Description

Name

The signal name should be same with its name from the "Instrument IO List", or similar document, provided by the control system design documentation. If it is user created it shall contain concise information about signal purpose or assignment. For example, if you have a valve HSV-001 the name of its closed position sensor can be "HSV_001_Position_Closed", or if you have proximity switch for object detection on Filling Station 1 it can be "FillSta1_Present". During the PLC generation, the signal name will become the PLC tag name for that signal.

Description

The signal description should provide additional details such as the signal's purpose, location, etc.

Signal Type

This refers to the name of the signal type, such as "DI_24VDC", "AI_4-20mA" etc.

The signal type has crucial role in PLC generation as it determines the PLC IO module to which the signal shall be wired. This is performed by the algorithm for signal IO List processing .

You can find the full list of supported signal types and their compatibility with the supported hardware platforms in the sectionCompatibility Between Signal Types and Hardware Platformson the "Hardware Platforms" page.

Hardware Platform

This refers to the name of the rack hardware platform (such as Simatic ET200MP, ET200SP, Mitsubishi i-QR etc.) where the signals should be wired to.

The hardware platform for the signal, does not necessarily have to be the same as the CPU hardware platform. Depending on your application, you can have multiple hardware platforms in the signals IO list. For example, you can wire the signals from the main cabinet to the ET200MP platform, while those from the distributed field cabinets, that have limited space, can be wired to the ET200SP platform.

Group

This refers to the name given to a group of signals that shall be wired to the separate PLC rack exclusively. This implies that one PLC rack can have signals from one group only. The group name is user defined on My Groups page, and can be a location, machine, production line, or any other relevant grouping criterion.

For example, if you have signals that are spread across 2 floors and plan to integrate them via remote IO racks on each floor, you could set the group for the signals from the first floor as "Floor1" and those from the second floor as "Floor2".

Before generating the PLC on the Generatepage, you will be asked to choose Main Rack Group to host the CPU module and to become "Main Rack".

3.

Column Requirements

In Table 1 are listed data processing requirements for each column of the Signal IO List for Single Fieldbus Architecture.

All requirements need to be satisfied in order for PLCCreator to process this IO list.

Column Name	Required	Unique	Requirements
Column NameName	RequiredRequired	UniqueUnique	Requirements Max length: 32 Allowed characters: A-Z, a-z, 0-9, _
Column NameDescription	RequiredOptional	Unique -	Requirements Max length: 256 Max length for Simatic Manager: 80 Allowed characters: A-Z, a-z, 0-9 and single _ . -
Column NameSignal Type	RequiredRequired	Unique -
Requirements To specify the "Signal Type", choose an option from the drop-down selection list of the "Signal Type" column entry in the signal IO list template. If pasting data in this column, ensure that pasted column entry can be found in this selection list. Figure 2: Selecting Signal Type in the IO List Figure 2: Selecting Signal Type in the IO List Before/during filling out the signal IO list, make sure that the selected signal type is compatible with the hardware platform you have specified in the "Hardware Platform" column. You can perform the compatibility check in the section Compatibility between Signal Types and Hardware Platformson the "Hardware Platforms" page. There are 2 types of signal IO list templates available in PLCCreator: With Common Set of Signal Types- This template has a shorter selection list that contains the signal types most commonly used in the industry. This signals set is supported by all hardware platforms. With Full Set of Signal Types- The selection list of this template contains all signal types supported by PLCCreator. Please note not all signal types are compatible with all hardware platforms.
Column NameHardware Platform	RequiredOptional	Unique -
Requirements To specify the "Hardware Platform", choose an option from the drop-down selection list of the "Hardware Platform" column entry in the IO list template. If pasting data in this column, ensure that pasted column entry can be found in this selection list. Figure 2: Selecting Hardware Platform in the IO List Figure 2: Selecting Hardware Platform in the IO List Before/during filling out the signal IO list, make sure that the selected hardware platform is compatible with the fieldbus protocol you plan to set on the PLC Architecture page. You can perform this compatibility check in the section Compatibility Between Communication Protocols and Hardware Platformson the "Hardware Platforms" page. It is also possible to not specify a hardware platform. In such cases, the CPU hardware platform specified on the CPU Datapage will be selected.
Column NameGroup	RequiredOptional	Unique -	Requirements The "Group" field is user-specified and must be registered on the groups table on My Groups page. If no group is specified, the default group "g1" will be assigned. On the Generatepage, you can even assign this group asMain Rack Groupto host the CPU module, becoming a "Main Rack".

Table 1: Column Data Requirements of Signal IO List for Single Fieldbus Architecture

4.

Example of Single Fieldbus Architecture

Let's take a simple use case example of the process system that contains signals located in 2 different locations: "Location1" and "Location2". It is required the signals in "Location1" to be integrated with "ET200MP" hardware platform. For "Location2" there are signals that need to be wired in the cabinet by using "ET200MP" and there are also signals that need to be integrated through cabinetless hardware "ET200Pro".

The expected PLC hardware configuration shall contain 3 remote IO racks as follows:

One ET200MP rack located in Location1
One ET200MP rack located in Location2
One ET200Pro rack located in Location2

The table below provides an example signal IO list for above use case example. To improve visibility, we have color-coded the signals belonging to each rack with green, blue, and yellow, respectively.

Name	Description	Signal Type	Hardware Platform	Group
System1_PT_0101	Pressure transmitter System1	AI_4-20mA	ET200MP	Location1
System1_FT_0101	Flow transmitter System1	AI_4-20mA	ET200MP	Location1
System1_FCV_0101_PositionOpened	Flow Control Valve System1 Position Open	DI_24VDC	ET200MP	Location1
System1_FCV_0101_PositionClosed	Flow Control Valve System1 Position Closed	DI_24VDC	ET200MP	Location1
System1_FCV_0101_PositionFeedback	Flow Control Valve System1 Actual Position	AI_4-20mA	ET200MP	Location1
System1_FCV_0101_PositionCommand	Flow Control Valve System1 Position Command	AO_4-20mA	ET200MP	Location1
System1_PT_0103	Pressure transmitter System1	AI_4-20mA	ET200MP	Location2
System1_FT_0103	Flow transmitter System1	AI_4-20mA	ET200MP	Location2
System1_FCV_0103_PositionOpened	Flow Control Valve System1 Position Open	DI_24VDC	ET200MP	Location2
System1_FCV_0103_PositionClosed	Flow Control Valve System1 Position Closed	DI_24VDC	ET200MP	Location2
System1_FCV_0103_PositionFeedback	Flow Control Valve System1 Actual Position	AI_4-20mA	ET200MP	Location2
System1_FCV_0103_PositionCommand	Flow Control Valve System1 Position Command	AO_4-20mA	ET200MP	Location2
System2_PT_0101	Pressure transmitter System2	AI_4-20mA	ET200Pro	Location2
System2_FT_0101	Flow transmitter System2	AI_4-20mA	ET200Pro	Location2
System2_FCV_0101_PositionOpened	Flow Control Valve System2 Position Open	DI_24VDC	ET200Pro	Location2
System2_FCV_0101_PositionClosed	Flow Control Valve System2 Position Closed	DI_24VDC	ET200Pro	Location2
System2_FCV_0101_PositionFeedback	Flow Control Valve System2 Actual Position	AI_4-20mA	ET200Pro	Location2
System2_FCV_0101_PositionCommand	Flow Control Valve System2 Position Command	AO_4-20mA	ET200Pro	Location2

The above signal IO list results in the PLC configuration shown in the Figure 2 below, assuming the user has selected the "Location1" as Main Rack Groupto host the CPU and to become "Main Rack". The small lists near each rack indicate the signals associated with that rack. As we can see, the signals distribution across the racks matches the uploaded signal IO list.
